Intel Integrated SR2520SAX RevIntel Integrated SR2520SAX Rev
ID: 90247880, SKU: SR2520SAXR
- 0 / 2 Intel
- 4x 3.5" SATA2, HotSwap, RAID 0 / 1 / 10
- 0 GB RAM (max. 16 GB), no optical drive
- 3x USB 2.0, 2x GB-LAN, RS-232 Interface
- Rack 2U
€ 844,-Ordered on demand
approx. 3-4 weeks delivery time
The Intel Server System SR2520SAXR represents the latest generation of enterprise-level, rack-optimized system solutions from Intel. Providing higher flexibility in data storage and security, this scalable, affordable system is ideal for growing companies running high transaction database applications.
This 2U fixed system is designed for organizations running front-end Internet, Web-hosting, and HPC applications. The 2U hot-swap system handles more demanding departmental database, datacenter and other high-transaction applications.
| |
Product Description |
Intel Server System SR2520SAXR - no CPU - Monitor : none. |
| |
EAN |
0735858197335
|
| |
Form Factor |
Rack-mountable - 2U |
| |
Dimensions (WxDxH) |
43 cm x 70.5 cm x 8.7 cm |
| |
Processor |
No CPU |
| |
Hard Drive |
No HDD |
| |
Networking |
Gigabit LAN |
| |
RAM |
0 MB (installed) / 16 GB (max) - DDR2 SDRAM - ECC |
| |
Storage Controller |
SATA (SATA-300) ; IDE |
| |
Graphics Controller |
ATI ES1000 |
| |
Type |
Server |
| |
Floppy Drive |
3.5" 1.44 MB floppy |
| |
Monitor |
None. |
| |
Processor Socket |
LGA771 Socket |
| |
Server Storage Bays |
Hot-swap 3.5" |
| |
Server Scalability |
2-way |
| |
Power Redundancy |
Yes |
| |
Video Memory |
16 MB DDR SDRAM |
|
| Processor / Chipset |
| |
Max CPU Qty |
2 |
| |
CPU Upgradability |
Upgradable |
| |
CPU |
No CPU |
| |
CPU Socket |
LGA771 Socket |
| |
Front Side Bus |
1333 MHz |
| |
Chipset Type |
Intel 5000V |
| Floppy Drive |
| |
Type |
3.5" 1.44 MB floppy |
| Dimensions & Weight |
| |
Width |
43 cm |
| |
Height |
8.7 cm |
| |
Depth |
70.5 cm |
| Hard Drive |
| |
Type |
No HDD |
| Storage Controller (2nd) |
| |
Type |
1 x IDE - integrated |
| Graphics Controller |
| |
Type |
Integrated |
| |
Video Interfaces |
VGA |
| |
Video Memory |
16 MB DDR SDRAM |
| |
Graphics Processor |
ATI ES1000 |
| Monitor |
| |
Monitor Type |
None. |
| Storage Controller |
| |
Channel Qty |
6 |
| |
RAID Level |
RAID 0, RAID 1, RAID 10 |
| |
Controller Interface Type |
SATA-300 |
| |
Type |
1 x SATA - integrated |
| Power |
| |
Installed Qty |
1 |
| |
Max Supported Qty |
2 |
| |
Device Type |
Power supply - hot-plug |
| |
Power Provided |
600 Watt |
| |
Power Redundancy |
Yes |
| |
Power Redundancy Scheme |
1+1 (with optional power supply) |
| Miscellaneous |
| |
Included Accessories |
Rack mounting kit |
| |
Features |
Power Factor Correction (PFC) |
| Networking |
| |
Type |
Integrated |
| |
Data Link Protocol |
Ethernet, Fast Ethernet, Gigabit Ethernet |
| |
Remote Management Protocol |
IPMI 2.0 |
| |
Ethernet Ports |
2 x Gigabit Ethernet |
| RAM |
| |
Installed Size |
0 MB / 16 GB (max) |
| |
Features |
Registered, Memory Mirroring, Fully Buffered |
| |
Form Factor |
FB-DIMM 240-pin |
| |
Technology |
DDR2 SDRAM - ECC |
| Expansion / Connectivity |
| |
Slots |
2 (total) / 2 (free) x CPU 8 (total) / 8 (free) x FB-DIMM 240-pin 1 (total) / 1 (free) x PCI-X / 100 MHz 1 (total) / 1 (free) x PCI-X / 133 MHz 1 (total) / 1 (free) x PCI 2 (total) / 2 (free) x PCIe x4 |
| |
Interfaces |
2 x LAN (Gigabit Ethernet) 1 x PS/2 keyboard 1 x PS/2 mouse 1 x serial 3 x USB 2.0 (1 in front) 1 x VGA |
| |
Bays |
1 (total) / 1 (free) x external 5.25" 1 (total) / 0 (free) x external 3.5" Slim Line 4 (total) / 4 (free) x hot-swap 3.5" x 1/3H |
| General |
| |
Front Accessible Bays Qty |
2 |
| |
Type |
Server |
| |
Hot-Swap Bays Qty |
4 |
| |
Server Scalability |
2-way |
| |
Product Form Factor |
Rack-mountable - 2U |
